Eco-friendly Air Cooled Dehumidifiers for Middle East Region are used for drying air of up to
95% relative humidity (RH) with temperatures from +15ºC to +45ºC. It is
widely used in the area of Middle East Region with tropical desert climate.
The applications are numerous and wide spread. Below are some examples:
- Surface treatment during internal blasting and painting of tanks
- Shipping industry, both for permanent and temporary applications
- Controlling humidity levels in production processes
- Protection of equipment sensitive to corrosion
- Climatic improvements in damp areas
Air
cooled dehumidifier is delivered as a complete unit with fans, filters,
condenser, evaporator, compressor and controls. The dehumidifier is
ready for site installation and connection to standard-size ducting.
Each dehumidifier will be custom designed according to the local
conditions and the needs of the customer.
ECO-FRIENDLY AIR COOLED DEHUMIDIFIER FOR MIDDLE EAST REGION
|
Model | KL-LFZ12000EF-E | KL-LFZ15000EF-E | KL-LFZ18000EF-E | KL-LFZ24000EF-E |
Process Airflow (m3/hr) | 12000 | 15000 | 18000 | 24000 |
Compressor Power (kw) | 75 | 43.5×2 | 50×2 | 67.5×2 |
Process Air Fan (kw) | 15
| 18.5 | 22 | 30 |
Reheating Power (kw) | 54 | 72 | 90 | 120 |
Outlet Connection (mm) | Φ280×4 | Φ300×4 | Φ250×6 | Φ300×6 |
Total Power (kw) | 156 | 193.5 | 234
| 309 |
| Equipment Size (mm) | 4300×2100×2550 | 5000×2200×2800 | 5300×2200×2800 | 5800×2200×3000 |
Weight (T) | 4.5
| 5.0
| 6.0
| 8.0
|
Machine Structure | Movable Containerized |
Temperature Control | High sensitive temperature sensor + PLC control + Touch Screen Display |
Refrigerant Gas
| R134A
|
Condenser
| Copper Tube + Aluminum Fins with Stainless Steel Casing Or Copper Tube + Copper Fins with Stainless Steel Casing |
| Evaporator | Copper Tube + Copper Fins with Stainless Steel Casing |
| Air Intake Condition | Temperature: 15~45°C，RH≤95% |
| Air Outlet Condition | Temperature: 25 ± 3°C，RH≤45% |
| Air Outlet Pressure | ≥2000~2500Pa |
| Electrical Control | 100% refrigeration + 100% Heating |
Note (All Models):
1. Power Supply: 3-phase plus earth 380V/ 415V / 50 Hz, 380V/440V/60Hz
2. Refrigerant: R134A
3. Cooling Step Control: 25%~50%~75%~100%
4. Cooling Media: Air
5. Discharge Condition: 25 ± 3 °C/RH below 45%
6.
We have the policy to improve our equipment continuously & shall
reserve the rights to change the dimensions and specs without prior
notice.
